File /B1945-1955 (03) - Architectural details, New Chapel, Trinity College, Toronto / Sir Giles Scott & Son, Architects, London, England. - scales vary. - dates vary.

Proposed Chapel: plan, side elevation, end elevation, longitudinal section, cross section (149-1) Proposed Chapel: plan, side elevation, longitudinal section, cross section (149-1b) Proposed Chapel: long elevation (east) showing porch, end elevation, cross section thro' tra... Proposed Chapel: long elevation (east) showing porch, end elevation, cross section thro' tra... Proposed Chapel: detail of apse buttresses (149-3) New Chapel: cross section, plan of apse & normal bay; normal bay external elevation, internal... New Chapel: details of arch between Chapel & transept; plan of transept (149-5) New Chapel: details of normal vaultings (149-6) New Chapel: details of vaulting piers to apse (149-7) New Chapel: details of cross-arches to side Chapel and arch between transept and side Chapel (149-8) New Chapel: details of windows to normal bays and apse (149-9) New Chapel: section showing arches to transepts & side Chapel; section through transept (149-10) New Chapel: section through chancel & side Chapel, showing apse; section through transept sho... New Chapel: details of narthex (149-12) Interior Elevation of North End; section through narthex looking east (two copies) (149-12a) New Chapel: details of interior stone work. - full scale. - August 1951. - (Received 27 February ... New Chapel: details of bases to normal vaulting piers. - full scale - August 1951. - (Received 27... New Chapel: details of staircase turret. -scale 1/2" = 1'-0" and full scale. - Sep... New Chapel: details of parapet & buttress tops. - full scale. - September 1951. - (Received 2... New Chapel: doorway to porch, plan, section, elevation, external elevation, internal elevation. -... New Chapel: details of arch to porch, doorway to porch & main external plinth to Chapel. - fu... New Chapel: details of doorway from narthex to existing corridor. - scale 1/2" = 1'-0&q... New Chapel: details of carving over doorway from narthex to existing corridor. - full scale. - Ju... New Chapel: north elevation of vestry. - scale 1/2" = 1'-0". - undated [1952] (149... New Chapel: revised details of porch. - scale 1/2" = 1'-0". - July 1952 (149-22) New Chapel: details of outer doorway to Chapel. - full scale. - July 1952 (149-23) New Chapel: elevations of apse buttresses; details of apse buttresses (149-24) New Chapel: elevation of wall across apse and reredos (149-25a) New Chapel: main reredos, rev. showing altar. - 18 August 1953 (149-25c) New Chapel: details of wall & doorways adjoining main reredos (149-26) New Chapel: details of main reredos (149-27) New Chapel: details of main reredos (149-28) New Chapel: details of main reredos (149-29) New Chapel: details of main reredos (149-30) New Chapel: details of main reredos (149-31) New Chapel: design for piscina (149-32) New Chapel: design for bronze screen in transept (two copies) (149-33) New Chapel: details of bronze screen in transept (149-35) New Chapel: details of bronze screen (cresting) in transept (149-36) New Chapel: design for organ case (two copies) (149-37) New Chapel: ceiling plan of side Chapel (149-38) New Chapel: details of organ case (also marked G&M, Dwg No. 225, 21 December 1954) (149-40) New Chapel: details of organ case (149-41) New Chapel: details of organ case (149-42) Details of don's stalls (149-43) Details of don's stalls (149-44) Details of kneelers to don's stalls (149-45) Design for kneelers in sanctuary (149-46) Design for kneelers in sanctuary (149-46a) Design for kneelers in sanctuary (149-46b)
